High-efficiency Packaging Machine & Tray Sealer – RDW500

Short Description:

Buy the RDW500 modified atmosphere preservation machine with fast, high-level, and intelligent integration. It features a fully automatic touch screen and high gas replacement rate to improve product shelf life. The best modified atmosphere box sealer in China, it ensures accurate box entry without jamming and offers stability and durability with its stainless steel structure. The aviation-grade anodized aluminum sealing mold guarantees no wear or deformation. Stand out with advanced inner edge sealing technology and precise sealing residence time for tight and beautiful packaging.

Send email to us

Product Detail

Product Tags

Specification

RDW550P
Dimension (m)	3.20.961.8	Film Width Max. (mm)	550*260
Tray size MAX. (mm)	450*300mm	MPa (V/Hz)	0.6 ~ 0.8
One cycle (s)	5~8	Power (KW)	220/50
Speed (Trays/h)	2160~1350 (3Trays/cycle)	Supply	3.8KW
Residual Oxygen Rate (%)	≤0.5%	Replacement Mwthod	Gas Flushing
Error (%)	≤1%	Mixer	/

Advantages

1.High efficiency, at least 10000 packages per day.

2.Safe and easy to operate with PLC touch screen operating system.

3.Provide full after-sale service, engineers are able to service overseas.

4.Automatic Production:Highly integrated package machine with tray forming, product filling area, sealing, gas flushing and die cutting. Reduce the risk of contacting insanitary source.

MAP Tray Sealing Machine has the functions of sealing. It adopts intelligent temperature controller and strong sealing function. It uses JAPANESE OMRON PLC. Stainless steel frame meets to food standard. The usage of pneumatic parts simplifies the mechanical structure, decrease the breakdown. The performance of the machine is more stable and safe. The machine is suitable for using roll of plastic film and aluminium film, it is widely used in food industry.
